FIREPROOF GLAZING WINDOWS
Fire-rated windows are the combination of fire-rated glass and frames. The windows hold enough time against fire hazards in buildings. They can withstand high temperatures and prevent the spread of flames and smoke. These windows are an essential feature in buildings where fire safety is concerned, including commercial buildings, hospitals, schools, high-rise apartments, etc. Fire-rated windows are necessary for many buildings according to the local building laws, codes and regulations in different countries to ensure buildings are constructed with appropriate fire safety measures. So fire-rated windows play a crucial role in protecting people and property from the devastating effects of fires.
Features:
Product:
The size and class is disigned according to the requirement from customers.
E30-EI180 is available.
VETROTECH CONTRAFLAM
The most versatile solution for applications demanding maximum Fire-Resistive protection in the largest possible dimensions.
CONTRAFLAM is a single or multi-chamber fire-resistive glass made of two or more sheets of toughened safety glass. The cavity between the glass sheets is sealed to be completely moisture-resistant, is then filled with an environmentally friendly, transparent and UV-stable intumescent interlayer that reacts when exposed to fire. The level of fire resistance required determines the number of sheets of toughened safety glass and interlayers included.
In the event of fire, it offers full heat insulation for the compartmentalization of fire. This product satisfies the highest demands of fire protection while offering robust handling and UV stability, with numerous configurations available.
- Available in single, double, or triple glazing (IGU)
- Rated for full fire-resistance from 45 to 120 minutes
- Symmetrical 1(B)1 impact resistance (EN 12600)
- Extended exposure time of 5,000 hours UV stability versus standard 2,000 hours
- Large variety of low-E and solar control coatings
- Exceptional U values (double glazing ≥ 0.9 W/m²K, triple glazing ≥ 0.5 W/m²)
- Available in large dimensions
- Moisture- and pressure-resistant edge sealing for extended durability
- Excellent acoustic insulation properties
- Many design and comfort options
- Manufactured locally for fast delivery and reduced CO2 emissions
- Can serve as laminated safety glass
- Easy, secure handling and installation
VETROTECH CONTRAFLAM STRUCTURE
Butt-joint fire-resistant glazing system for interior & exterior applications (under specific conditions)
CONTRAFLAM Structure sets new standards in the design of transparent fire protection. The floor-to-ceiling glazing system provides a continuous, uninterrupted glass wall, joined only with silicone. Made of CONTRAFLAM fire-resistant glass, CONTRAFLAM Structure is engineered to achieve the mechanical resistance required to support interior wall line-loads and offer superior edge aesthetic.
- Available in single, double (DGU),
- Available in Fire-Resistive ratings for 60 and 120 minutes.
- Symmetrical impact resistance (ANSI Z97.1, CPSC 16CFR 1201-CAT II, CAN/CGSB - 12.1-M90 )
- Extended exposure time of 5,000 hours. Outstanding durability and UV-stability.
- Available in large dimensions of up to 138 1/2in exposed for 60 minute rating, 126in exposed for 120 minute rating.
- Visually continuous expanse of glass delivers maximum transparency
- Symmetrical butt-joint fire protection
- For interior and exterior applications* (*under specific conditions)
- Portrait and landscape applications tested
- Ceramic frit back-painted vertical edges in any colorSlim silicone joints in black
- Excellent acoustic insulation properties
PILKINGTON PYRODUR
Clear Integrity Fire Barrier - Plus protection against radiant heat.
Pilkington Pyrodur
- Based on intumescent technology
- Class 30 and 60 mins integrity (E)(2)
- Protection from radiant heat (EW30) and added insurance of insulation for 15 minutes (EI)(2)
- Impact safety class up to 1(B)1(1)
